The Best Robinair 15400 Vacuum Pump

Robinair’s No 15400 CoolTech 2-stage rotary vane design vacuum pump features a 4 CFM free air displacement along with the power and capacity needed for a wide range of service applications. This high-performance unit includes a heavy duty, 1/2 HP, 115V/60Hz thermally protected motor that delivers high torque for easy startup and efficient operation. Factory rated to 15 microns, this unit delivers a fast, thorough evacuation. Offset rotary vanes build powerful compression within the pumping chamber – reducing pressure and vaporizing moisture. Gas Ballast design mixes moisture laden air passing through pump with relatively dry air so compression doesn’t cause condensation. Iso-Valve isolates pump from system with just a quarter turn. Durable molded polycarbonate base improves pump balance and minimizes vibration while in operation. Also includes: ¼” and ½”male flare inlet fittings, easy to read sight glass, easy access oil fill port, and angled oil drain valve for faster, more complete draining of the reservoir. Thoughtful design and robust construction ensure this UL approved unit will deliver the high-performance professionals demand. Robinair CoolTech vacuum pumps are designed for use on A/C-R systems using CFCs, HCFCs, and HFCs in conjunction with mineral oil, ester oil, alkylbenzene oil, and PAG oil as lubricants. Not for use with ammonia or lithium bromide systems; not for use with flammable refrigerants. Oil included. Robinair, a Bosch Automotive Service Solutions brand, is a global leader in service tools and equipment based in Owatonna, Minnesota. Robinair is recognized throughout the world as the quality and performance leader in AC/R evacuation tools and this position has led to its success with the full range of products that serve the heating/ventilating/air conditioning/refrigeration (HVAC-R) and mobile markets, which includes the automotive aftermarket along with other industries such as agriculture and construction.

Robinair’s 15800 VacuMaster Economy Vacuum Pump is a high performance, heavy duty 2-Stage rotary vane design vacuum pump designed for commercial refrigeration use. With an 8 CFM free air displacement, factory rating to 40 microns, and 18.6 ounce oil reservoir, this unit has the capacity you need to get the job done. This robust unit features a 1 HP, 115V, 60 Hz thermally protected motor; an inlet fitting engineered for maximum airflow while preventing oil backflow; finned aluminum surfaces that dissipate heat faster (keeping pump cooler and extending life); 1/4″ & 3/8″ MFL inlet fittings; easy to read sight glass; easy access oil fill port; oil drain valve positioned at the bottom of the oil reservoir and angled for faster, more complete draining, and non-skid feet. Oil included. Robinair, a Bosch Automotive Service Solutions brand, is a global leader in service tools and equipment based in Owatonna, Minnesota. Robinair is recognized throughout the world as the quality and performance leader in AC/R evacuation tools and this position has led to its success with the full range of products that serve the heating/ventilating/air conditioning/refrigeration (HVAC-R) and mobile markets, which includes the automotive aftermarket along with other industries such as agriculture and construction.

Robinair’s No 15600 CoolTech 2-stage rotary vane design vacuum pump features a 6 CFM free air displacement along with the power and capacity needed for a wide range of service applications. This high-performance unit includes a heavy duty, 1/2 HP, 115V/60Hz thermally protected motor that delivers high torque for easy startup and efficient operation. Factory rated to 15 microns, this unit delivers a fast, thorough evacuation. Offset rotary vanes build powerful compression within the pumping chamber – reducing pressure and vaporizing moisture. Gas Ballast design mixes moisture laden air passing through pump with relatively dry air so compression doesn’t cause condensation. Iso-Valve isolates pump from system with just a quarter turn. Durable molded polycarbonate base improves pump balance and minimizes vibration while in operation. Also includes: 1/4″, 3/8″ and 1/2″ male flare inlet fittings, easy to read sight glass, easy access oil fill port, and angled oil drain valve for faster, more complete draining of the reservoir. Thoughtful design and robust construction ensure this UL approved unit will deliver the high-performance professionals demand. Robinair CoolTech vacuum pumps are designed for use on A/C-R systems using CFCs, HCFCs, and HFCs in conjunction with mineral oil, ester oil, alkylbenzene oil, and PAG oil as lubricants. Not for use with ammonia or lithium bromide systems; not for use with flammable refrigerants. Oil included. Robinair, a Bosch Automotive Service Solutions brand, is a global leader in service tools and equipment based in Owatonna, Minnesota. Robinair is recognized throughout the world as the quality and performance leader in AC/R evacuation tools and this position has led to its success with the full range of products that serve the heating/ventilating/air conditioning/refrigeration (HVAC-R) and mobile markets, which includes the automotive aftermarket along with other industries such as agriculture and construction.

The Robinair 15434 CoolTech vacuum pump features power and capacity for a wide range of service applications, a high CFM rating for fast, thorough evacuation and a two-stage rotary design. Features: Iso-Valve – Isolates the pump from the system with just a quarter-turn; Gas Ballast – Moisture laden air passing through the pump mixes with relatively dry air to such a degree that compression does not cause condensation; Two-stage Design – Cleans the system more thoroughly than a single-stage pump, the second stage starts pumping at a lower pressure so you can pull a deeper, ultimate vacuum; Oil Drain Valve – Positioned at the bottom of the oil reservoir and angled for faster, more complete draining; Oil Fill Port – Makes adding oil simple since the port is accessible from the front or either side. The sight glass on the front of the pump shows you when enough oil has been added; Heavy-Duty Motor – High torque design for easy startup and efficient operation; Offset Rotary Vanes – Our proven design builds a powerful compression within the pumping chamber to reduce system pressure and vaporize moisture so it can be exhausted along with air; Molded Base – Durable polycarbonate base improves pump balance and minimizes vibration during operation; and Die-Cast Aluminum Housing – Cast aluminum housings make the pumps lightweight but durable.

Robinair’s No. 15337 Replacement Vacuum Pump Module Cover/Oil Reservoir is a genuine Robinair replacement part for Robinair 15400 and 15600 series vacuum pumps. OE form, fit, and function guarantees perfect fit and easy installation. Diecast aluminum construction. Gasket included. Robinair, a Bosch Automotive Service Solutions brand, is a global leader in service tools and equipment based in Owatonna, Minnesota. Robinair is recognized throughout the world as the quality and performance leader in AC/R evacuation tools and this position has led to its success with the full range of products that serve the heating/ventilating/air conditioning/refrigeration (HVAC-R) and mobile markets, which includes the automotive aftermarket along with other industries such as agriculture and construction.
